KST X08 Plus V6.0 – High-Performance 8mm Micro Servo

Ultra-thin. Lightweight. Powerful.

The KST X08 Plus V6.0 is a high-performance micro servo designed for demanding RC models where space, weight, speed and precision matter.

At just 8 mm thick and approximately 9 g, the X08 Plus fits perfectly into thin wings and other tight installations. Despite its compact dimensions, the powerful coreless DC motor and hardened steel geartrain deliver up to 5.3 kg·cm of torque at 8.4V and an impressive 0.09 sec/60° speed.

The X08 Plus is an upgraded version of the proven KST X08, featuring a larger motor and an improved geartrain designed to provide excellent precision, durability and minimal play.

Built for High-Performance Models

The combination of high torque, fast response and ultra-compact dimensions makes the X08 Plus an excellent choice for:

• F5J and F3J gliders

• F5D / pylon racers

• High-performance electric gliders

• EDF jets

• Lightweight aerobatic and sport models

• Thin-wing applications where conventional servos are too large

High Voltage Flexibility

The X08 Plus offers an exceptionally wide operating voltage range from 3.8V to 8.4V, allowing it to be used with both 1S and 2S LiPo/Li-ion power systems.

At 8.4V, it delivers 5.3 kg·cm of torque with a response time of just 0.09 sec/60°, giving you fast and precise control when it matters most.

Precision Metal Geartrain

The aluminium alloy case provides excellent strength and heat dissipation, while the hardened steel gears are engineered for demanding applications. KST's precise manufacturing tolerances help minimize gear play and maintain accurate control over time.

Small enough for the tightest installations. Powerful enough for serious performance.

Key Features

• Ultra-thin 8 mm design

• Only approximately 9 g

• Up to 5.3 kg·cm torque @ 8.4V

• Up to 0.09 sec/60° speed @ 8.4V

• 3.8–8.4V operating range

• Powerful coreless DC motor

• Hardened steel gears

• Precision aluminium alloy case

• Excellent heat dissipation

• Low gear play for precise control

• Ideal for high-performance gliders, racers and EDF models

Specifications

KST X08 Plus V6.0

A serious performance servo in an incredibly small package.
With its 8 mm thin profile, 9 g weight, high torque and exceptional speed, the X08 Plus V6.0 is an ideal choice for pilots who demand maximum performance without adding unnecessary weight or taking up valuable space.
