FEATURES:

Hybrid construction from wood and composite materials for specially reinforced fuselage and wings.

NEW Patented quick assembly system for wings, stabilizer(no need tools require)

NEW this airframe can provide great 3D performance on popular engine like DLE35 , DA35 , GP38.

 Patented quick assembly system for canopy.

Highly prefabricated, experienced builders can have air ready in under a day

Pre-installed hinges (glued and pinned)

NEW fuel tank spot on the CG top of wing tube same as 120cc size to avoid CG change during flight.

NEW design 2 middle size servo elevator for better adjustable on elevator 21kg

Internally mounted cowling – so no visible external screws exposed

Removable wings and stabs

Laser engraved motor mounting position

Easy canister installation due to open construction

Included hardware:

Complete air frame with all basic accessories (such as carbon fibre main undercarriage, tail-gear assembly and wing-tubes as well as fibreglass control horns and wheel pants)

Pre-installed hinges and pre-mounted canopy

Fuel tank and fuel tubing pre-prepared, fuel dot and breather valve

Wheels, axels and wheel pants

Pre-prepared pull-pull wires and pushrods with ball links

Matching carbon spinner,3.5″

Required hardware:

Motor: 30-40cc or equivalent electric

Required Servos:

3x Standard High Torque (Ailerons & Rudder – 20x40mm)  AGF A72BHX 26KG

2x Mini High Torque (Elevators – 15x35mm) AGF midi servo A35BHLP

1x Standard (Throttle for gas engine) AGF B53DHS

Expert Choice: We recommend using AGF servos for this airframe to ensure maximum precision and durability during extreme aerobatics.

Also requires all the usual accessories such as transmitter, receiver, propeller, batteries, powerbox, extension leads and possibly other small accessories.

Extension wire lengths:

Each aileron:
15cm
( to reach receiver direct)

Each elevator:
65cm

Rudder:

65cm
(when using direct – if installing pull pull, no required extension)

CENTER OF GRAVITY:

soon
Measured back from leading edge of the wing at the fuselage.

You will find a laser engraved C.G. emblem on the inside of the fuselage, located close to the wing tube, which also shows the exact location for Center of Gravity.
